๐Ÿฅท Formal verification of LLZK circuits in Rocq

ยท 10 min read

In this blog post, we present a short example about how we define reasoning rules in Rocq to formally verify the safety of zero-knowledge circuits written in LLZK.

Follow-up

This blog post is a follow-up to:

The code we are referring to in this post is available in github.com/formal-land/garden/Garden/LLZK.

Green forest

๐Ÿงฎ Reasoning rulesโ€‹

As we use a free monad to represent the effectful operations of LLZK, we need to define reasoning rules to evaluate each operator.

In order to optimize the proofs for the verification of safety properties (no under-constraints), we will assume that the execution of LLZK terms is always complete. By complete, we mean that there are no out-of-bound accesses in arrays. We also mean that we initialize each value exactly once, for the pattern where we declare an array and then set its elements in a second step, for example.

For the circuits, this is a reasonable assumption, as they are executed only once, unrolling all the loops and function calls in a large set of polynomial equations. For the compute functions that generate the witnesses, since they are stored off-chain, we can always upgrade them if we realize they are not complete. A proof of completeness for the compute functions could be done independently using a dedicated semantics.

We define a predicate:

{{ e ๐Ÿ”ฝ result , P }}

saying that a monadic computation e can reduce to the value output, and that its successful execution implies that the predicate P holds. The predicate P typically applies to the input and output field variables of the circuit. A typical predicate is:

output=expected_output(input)\text{output} = \text{expected\_output(\text{input})}

stating that the circuit is deterministic.

The main reasoning rules are, in Rocq code:

Inductive t : forall {A : Set}, M.t A -> A -> Prop -> Prop :=
| Pure {A : Set} (value : A) :
{{ M.Pure value ๐Ÿ”ฝ value, True }}
| AssertEqual {A : Set} (x1 x2 : A) :
{{ M.AssertEqual x1 x2 ๐Ÿ”ฝ tt, x1 = x2 }}
| CreateStruct {A : Set} (value : A) :
{{ M.CreateStruct ๐Ÿ”ฝ value, True }}
| FieldWrite {A : Set} (field : A) :
{{ M.FieldWrite field field ๐Ÿ”ฝ tt, True }}
| Let {A B : Set} (e : M.t A) (k : A -> M.t B) (value : A) (output : B) (P1 P2 : Prop) :
{{ e ๐Ÿ”ฝ value, P1 }} ->
(P1 -> {{ k value ๐Ÿ”ฝ output, P2 }}) ->
{{ M.Let e k ๐Ÿ”ฝ output, P1 /\ P2 }}
| Implies {A : Set} (e : M.t A) (value : A) (P1 P2 : Prop) :
{{ e ๐Ÿ”ฝ value, P1 }} ->
(P1 -> P2) ->
{{ e ๐Ÿ”ฝ value, P2 }}

where "{{ e ๐Ÿ”ฝ output , P }}" := (t e output P).

Pureโ€‹

There is nothing special to say about the rule of the M.Pure operator of the monad. We return the value that we are supposed to return, whether it is in a fully evaluated form or still as an expression with some free variables. The predicate is True as we do not assert any constraints.

AssertEqualโ€‹

For the M.AssertEqual operator, we always return the unit value tt, and we assert that the two parameters are equal. The predicate is the equality between the two parameters, as this is the condition to successfully execute the operator.

CreateStructโ€‹

With this operator, we can declare a new structure element, whose fields are to be set later. This is a non-deterministic operation, and we let the user choose the value of the structure when verifying the circuit. However, in practice, there is only one possible choice as the value of the structure must be compatible with the write operations that will follow.

FieldWriteโ€‹

This operator is used to write a value in a field of a structure. We can apply this rule only if we have chosen the right value for the structure. We assume that all LLZK functions are complete, which can be checked at runtime, so that each declared structure has exactly one write operation, and we cannot make a read before the write.

Letโ€‹

The Let rule is for the binding operator of the monad. It combines the conditions P1 and P2 to form a new predicate P1 /\ P2 for the execution of e and k. We can also use the knowledge of P1 to reason about the execution of k.

Impliesโ€‹

Finally, the Implies rule is used to simplify the expression of the predicate P. We generally wrap our proofs in an Implies call to have a clean predicate at the end. Otherwise, the final expression would contain a lot of clutter, like True /\ ... operations.

๐Ÿ“ Exampleโ€‹

We now look at the specification and verification of the LLZK example we took at the beginning of this blog post series:

function.def @global_add(%a: !felt.type, %b: !felt.type) -> !felt.type {
%c = felt.add %a, %b
function.return %c : !felt.type
}

struct.def @Adder {
struct.field @sum : !felt.type {llzk.pub}

function.def @compute(%a: !felt.type, %b: !felt.type) -> !struct.type<@Adder> {
%self = struct.new : !struct.type<@Adder>
%sum = function.call @global_add(%a, %b) : (!felt.type, !felt.type) -> (!felt.type)
struct.writef %self[@sum] = %sum : !struct.type<@Adder>, !felt.type
function.return %self : !struct.type<@Adder>
}

function.def @constrain(%self: !struct.type<@Adder>, %a: !felt.type, %b: !felt.type) {
%sum = struct.readf %self[@sum] : !struct.type<@Adder>, !felt.type
%c = function.call @global_add(%a, %b) : (!felt.type, !felt.type) -> (!felt.type)
constrain.eq %sum, %c : !felt.type
function.return
}
}

global_addโ€‹

For the global_add function, we write the following specification in the file Garden/LLZK/verification.v:

Lemma global_add_eq {p} `{Prime p} (x y : Felt.t) :
{{ global_add x y ๐Ÿ”ฝ (x + y) mod p, True }}.

The generated Rocq translation of the global_add function is:

Definition global_add {p} `{Prime p} (arg_fun_0 : Felt.t) (arg_fun_1 : Felt.t) : M.t Felt.t :=
let var_0 : Felt.t := BinOp.add arg_fun_0 arg_fun_1 in
M.Pure var_0.

We can now prove the specification with the application of the single rule Run.Pure, as the code is purely functional:

Proof.
apply Run.Pure.
Qed.

Most of the auxiliary functions or the compute functions will have a specification of a similar form, where the predicate is True.

computeโ€‹

The translation of the compute function is:

Definition compute {p} `{Prime p} (arg_fun_0 : Felt.t) (arg_fun_1 : Felt.t) : M.t Adder.t :=
let* var_self : Adder.t := M.CreateStruct in
let* var_0 : Felt.t := global_add arg_fun_0 arg_fun_1 in
let* _ : unit := M.FieldWrite var_self.(Adder.sum) var_0 in
M.Pure var_self.

Here, there are some side-effects composed with the M.Let operator, noted let*. We can apply the Run.Let rule to prove the specification:

Definition spec {p} `{Prime p} (x y : Felt.t) : Adder.t :=
{|
Adder.sum := (x + y) mod p;
|}.

Lemma compute_eq {p} `{Prime p} (x y : Felt.t) :
{{ Adder.compute x y ๐Ÿ”ฝ
spec x y, True
}}.
Proof.
unfold Adder.compute.
eapply Run.Implies. {
eapply Run.Let. {
eapply Run.CreateStruct with (value := Adder.Build_t _).
}
intros _.
eapply Run.Let. {
apply global_add_eq.
}
intros _.
eapply Run.Let. {
eapply Run.FieldWrite.
}
intros _.
apply Run.Pure.
}
easy.
Qed.

The specification states that we are creating a structure with the addition modulo p of the two input parameters. We make the proof with a succession of Run.Let rules. For the line:

let* var_self : Adder.t := M.CreateStruct in

we apply the Run.CreateStruct rule, with an existential variable _ for the field of the structure. This existential variable is later unified with the right value when we evaluate the line:

let* _ : unit := M.FieldWrite var_self.(Adder.sum) var_0 in

which forces its value to be var_0.

The last tactic:

easy.

at the end of the proof is there to aggregate the predicate True /\ ... /\ True that we obtain from the Run.Let rules into a single True.

constrainโ€‹

The translation of the constrain function is:

Definition constrain {p} `{Prime p}
(arg_fun_0 : Adder.t) (arg_fun_1 : Felt.t) (arg_fun_2 : Felt.t) :
M.t unit :=
let var_0 : Felt.t := arg_fun_0.(Adder.sum) in
let* var_1 : Felt.t := global_add arg_fun_1 arg_fun_2 in
let* _ : unit := M.AssertEqual var_0 var_1 in
M.Pure tt.

We specify it as follows:

Lemma contrain_implies {p} `{Prime p}
(self : Adder.t)
(x y : Felt.t) :
let self := map_mod self in
{{ Adder.constrain self x y ๐Ÿ”ฝ
tt,
self = spec x y
}}.

Here, we always return the unit value tt, and we assert that the self parameter must be equal to the expected structure containing the sum of the two input parameters. Note that we use the map_mod function to make sure to apply the modulo operation to the fields of the structure, as otherwise they could be arbitrary Z values. This is a way to express that we consider equality to be modulo p.

No under-constraints

This specification states that there are no under-constraints in the constrain function. Indeed, the self parameter is only allowed to be equal to a single value spec x y. However, we do not show that the circuit is not over-constrained: we show that all solutions must be equal to spec x y, but there might be no solutions, and this statement would hold.

The no over-constraints property is generally considered less critical than the no under-constraints property, and easier to formally verify: it amounts to verifying that the expected output validates all the assertions of the circuit.

For the proof, we again apply the Run.t rules in a straightforward way:

Proof.
unfold Adder.constrain.
eapply Run.Implies. {
eapply Run.Let. {
apply global_add_eq.
}
intros _.
eapply Run.Let. {
apply Run.AssertEqual.
}
intros _.
apply Run.Pure.
}
unfold spec.
hauto lq: on.
Qed.

โœ’๏ธ Conclusionโ€‹

We have seen how to formally specify and verify the safety of an LLZK circuit in Rocq. There are a few things that need to be improved now:

  • Adding more automation to the proofs: as you can see, they are rather verbose, even if LLM auto-complete catches repetitive patterns.
  • Adding more support for the LLZK language, translating bigger examples (in the thousands of lines, the one above is 500 lines long). Indeed, other .llzk files use features that we do not support yet, like arrays whose size is dynamic with respect to a for loop counter. Our plan is to add dynamic typing rules capabilities in a refined version of our reasoning rules.
