LLZK is a language designed to implement zero-knowledge circuits. We wrote a translation tool from this language to a representation in the formal language Rocq.

In this blog post, we present how we give a semantics to all the primitive operations of LLZK in Rocq. The end-goal is to provide a way to formally verify that a zero-knowledge circuit is safe, that is to say, without under-constraints.

Follow-up

This blog post is a follow-up to:

• 🥷 Beginning of a formal verification tool for LLZK

The code we are referring to in this post is available in github.com/formal-land/garden/Garden/LLZK.

Discuss with us!

The cost of a bug is extremely high in some industries (loss of life, loss of money, etc.), while there exist technologies like formal verification to make sure programs are correct for all cases.

Many companies and institutions like Ethereum are already using formal verification to secure their operations.

Contact us at  💌contact@formal.land to discuss! 👋

🪆 Data types

Here are the main data types that we see appearing in LLZK code examples:

• Felt.t, for integers modulo $p$ a large prime number. We represent them with the type of unbounded integers $\mathbb{Z}$, and explicitly compute the modulo on the result of each operation.
• i1, for boolean values. We represent them with the boolean type bool of Rocq.
• Index.t for length or indexes in arrays. We represent them with the type nat of Rocq (non-negative integers).
• Array.t for arrays, parametrized by a list of dimensions and a type of elements. We design a custom type for these.
• Structures, defined in an LLZK module with a list of fields. We represent them with a record type in Rocq.

Felt.t

We define the primitive arithmetic operations on Felt.t as pure functions in Rocq, parametrized by an implicit prime number $p$. For example, for the binary operations we do:

Module BinOp.
  Definition add {p} `{Prime p} (x y : Z) : Z :=
    (x + y) mod p.

  Definition sub {p} `{Prime p} (x y : Z) : Z :=
    (x - y) mod p.

  Definition mul {p} `{Prime p} (x y : Z) : Z :=
    (x * y) mod p.

  Definition div {p} `{Prime p} (x y : Z) : Z :=
    (x / y) mod p.

  Definition mod_ {p} `{Prime p} (x y : Z) : Z :=
    (x mod y) mod p.
End BinOp.

We do not check if the parameters are in the bounds $0 \leq n < p$, but we apply the modulo operation on the result of each function. This is a convention that we will try to use for the rest of the formalizations.

Array.t

We represent arrays as a record wrapping a get function:

Record t {A : Set} {Ns : list nat} := {
  get : MultiIndex.t Ns -> A;
}.
Arguments t : clear implicits.

We use a function rather than a list, as in our experience, for many zero-knowledge circuits, there exists an expression relating the values in an array to their indices. A limitation is that we need to find a default value for out-of-bounds indexes. This is generally easy to find, as most data structures are built around the Felt.t type with zero as a default value.

Because arrays can be multi-dimensional, define a type for multi-dimensional indices instead of using a plain nat:

Module MultiIndex.
  Fixpoint t (Ns : list nat) : Set :=
    match Ns with
    | nil => unit
    | _ :: Ns => Index.t * t Ns
    end.
End MultiIndex.

A multi-index is simply a tuple with as many integers as there are dimensions. We prefer to use an array with multi-indices instead of arrays of arrays, in order to have a representation following the choices of LLZK.

There is an array.extract operator in LLZK, to extract a sub-array from an array, which isgeneralized to the case of multidimensional arrays. We define it as:

Definition extract {A : Set} {Ns Ms : list nat}
    (array : t A (Ns ++ Ms))
    (indexes : MultiIndex.t Ns) :
    t A Ms :=
  {|
    get indexes' := array.(get) (MultiIndex.concat indexes indexes');
  |}.

It takes an array whose multi-dimension is a list of dimensions Ns followed by dimensions Ms. It returns a sub-array whose multi-dimension is Ms. It relies on an operator MultiIndex.concat to concatenate two multi-indexes of the right dimensions:

Fixpoint concat {Ns Ms : list nat}
    (indexes : MultiIndex.t Ns)
    (indexes' : MultiIndex.t Ms) :
    MultiIndex.t (Ns ++ Ms) :=
  match Ns, indexes with
  | nil, _ => indexes'
  | _ :: Ns, (index, indexes) => (index, concat indexes indexes')
  end.

Structures

We found that directly using the Record construct of Rocq to represent structures was enough. Here is how a typical structure is defined in LLZK:

struct.def @MatrixConstrain {
    struct.field @check0 : !struct.type<@ArrayConstrain<[7, 11]>>
    struct.field @check1 : !struct.type<@ArrayConstrain<[13, 17]>>
}

This is translated to a record type in Rocq:

Module MatrixConstrain.
  Record t : Set := {
    check0 : ArrayConstrain.t 7 11;
    check1 : ArrayConstrain.t 13 17;
  }.
End MatrixConstrain.

🔮 Monad

While we try to represent as many operations as possible in the purely functional fragment of Rocq, since it simplifies formal reasoning, for some operations we must use a monad. The main monadic operation is the check of equality between two integers modulo $p$. This is the main building block for circuits, to ensure that only valid witnesses are accepted.

We design our monad as a free-monad, in order to be able to define the reasoning rules independently:

Module M.
  Inductive t : Set -> Set :=
  | Pure {A : Set} (value : A) : t A
  | AssertEqual {A : Set} (x1 x2 : A) : t unit
  | AssertIn {A : Set} {Ns : list nat} (x : A) (array : Array.t A Ns) : t unit
  | AssertBool (value : bool) : t unit
  | CreateStruct {A : Set} : t A
  | ArrayWrite {A : Set} {Ns : list nat}
      (array : Array.t A Ns)
      (indexes : Array.MultiIndex.t Ns)
      (value : A) :
      t unit
  | FieldWrite {A : Set} (field : A) (value : A) : t unit
  | Let {A B : Set} (e : t A) (k : A -> t B) : t B
  .
End M.

The two standard monadic operators are:

• Pure that we note M.Pure, and
• Let that we note let* x := ... in ....

We also define some primitives, in particular:

• AssertEqual typically used to enforce the equality between two integers modulo $p$.
• AssertIn to check that an element is in an array.
• CreateStruct to instantiate a value for a structure in a non-deterministic way. The structure is to be defined in subsequent write operations.
• FieldWrite to write a value in a field of a structure and force its definition.

✒️ Conclusion

We have seen how to define the main primitives for the LLZK language in Rocq. In the upcoming blog posts, we will show how to reason about LLZK circuits in Rocq, thanks to the introduction of reasoning rules for each monadic operation.
