🥷 Verification of the completeness of an OpenVM chip

In our previous blog post 🥷 Formal verification of an OpenVM chip, we have seen how to verify the determinism of the branch_eq chip of OpenVM. Now, we will see how to verify its completeness, meaning that it always accepts a valid witness for any possible input.

info

This work was funded by a grant from the Ethereum Foundation to whom we are thankful, as part of the zkEVM Formal Verification Project, to "accelerate the application of formal verification methods to zkEVMs".

🎄 Completeness for circuits

The completeness property for a circuit says that for any given set of well-formed input variables, there exists a set of output variables that satisfies the circuit.

Security implications

It means that the circuit, generally representing a VM, will never reach a state where it is blocked, which would be a denial of service attack.

To state this property with quantifiers, let us consider a circuit $\mathcal{C}$ parametrized by some variables that we group into the categories of input, output, and oracle variables (values given by the prover and verified by the circuit to speed up some computations). We say that the circuit is complete if:

$$\forall\ \text{input},\\ \exists\ \text{output}, \text{oracle},\\ \mathcal{C}(\text{input}, \text{output}, \text{oracle}) \text{ holds}$$

Now, in our Garden framework for circuits' formal verification, how do we define reasoning rules to show completeness? 🤔

In practice, we have an explicit function representing the output variables that we want, as circuits are supposed to be deterministic for security reasons. So showing completeness amounts to verifying that for the expected output of the circuit, all constraints are satisfied.

We define this predicate as follows:

{{ e ✅ value }}

where e is of type M.t A and value is of type A. It says that a circuit e in closed form, so applied to all its input and output variables, will evaluate to value satisfying all the constraints.

Generally the result value value will be the unit value as circuits do not return anything, but for intermediate circuits it can be a structure of polynomial expressions, composed with other sub-circuits to build the final zkVM circuit.

We define the completeness predicate following the constructors of the monad M.t, with one rule per constructor:

Inductive t {A : Set} : M.t A -> A -> Prop :=
| Pure (value : A) :
  {{ M.Pure value ✅ value }}
| AssertZero (x : Z) (value : A) :
  x = 0 ->
  {{ M.AssertZero x value ✅ value }}
| Call (e : M.t A) (value : A) :
  {{ e ✅ value }} ->
  {{ M.Call e ✅ value }}
| Let {B : Set} (e : M.t B) (value : B) (k : B -> M.t A) (value_k : A) :
  {{ e ✅ value }} ->
  {{ k value ✅ value_k }} ->
  {{ M.Let e k ✅ value_k }}
| When (condition : Z) (e : M.t A) (value : A) :
  (condition <> 0 -> {{ e ✅ value }}) ->
  {{ M.When condition e ✅ value }}.

Here are some comments about the rules:

• Pure: we directly return the value value that we are supposed to return. This is the case for purely functional circuits.
• AssertZero: we assert that the parameter x is equal to 0. This is the main primitive to assert the constraints. We check the equality between the polynomial expression x and 0 in Z as we compute the modulo after each primitive polynomial operation, and we compare that all operations are correctly applied by comparison with the Rust implementation.
• Call: this is a utility wrapper to simplify the composition of sub-circuits by giving an explicit way to mark limits. It does nothing except unwrap the M.Call constructor.
• Let: for the binding constructor, the most important constructor in a monad, we state that a circuit is complete if both the circuits e and k applied to the result of e are complete.
• When: we conditionally evaluate a sub-circuit e and we assert that it evaluates to value. We show the completeness of e under the condition that condition is not zero. In practice, value will always by the unit value (this is the case on Plonky3 circuits).

🛡️ For branch_eq

If we take again the branch_eq chip of OpenVM, located in github.com/openvm-org/openvm/extensions/rv32im/circuit/src/branch_eq/core.rs, we state its completeness as follows:

Lemma eval_complete `{Prime goldilocks_prime} {NUM_LIMBS : Z}
    (self : BranchEqualCoreAir.t NUM_LIMBS)
    (a' : Array.t Z NUM_LIMBS)
    (b' : Array.t Z NUM_LIMBS)
    (imm' : Z)
    (diff_inv_marker' : Array.t Z NUM_LIMBS)
    (from_pc' : Z)
    (branch_equal_opcode : BranchEqualOpcode.t)
    (H_NUM_LIMBS : 0 <= NUM_LIMBS) :
  let a := M.map_mod a' in
  let b := M.map_mod b' in
  let imm := M.map_mod imm' in
  let diff_inv_marker := M.map_mod diff_inv_marker' in
  let from_pc := M.map_mod from_pc' in
  let expected_cmp_result := get_expected_cmp_result branch_equal_opcode a b in
  let local :=
    {|
      BranchEqualCoreCols.a := a;
      BranchEqualCoreCols.b := b;
      BranchEqualCoreCols.cmp_result := Z.b2z expected_cmp_result;
      BranchEqualCoreCols.imm := imm;
      BranchEqualCoreCols.opcode_beq_flag :=
        match branch_equal_opcode with
        | BranchEqualOpcode.BEQ => 1
        | BranchEqualOpcode.BNE => 0
        end;
      BranchEqualCoreCols.opcode_bne_flag :=
        match branch_equal_opcode with
        | BranchEqualOpcode.BEQ => 0
        | BranchEqualOpcode.BNE => 1
        end;
      BranchEqualCoreCols.diff_inv_marker := diff_inv_marker;
    |} in
  forall
    (* We assume a [diff_inv_marker] oracle with the following property *)
    (H_diff_inv_marker :
      if Array.Eq.dec a b then
        (* It can be anything in case of equality *)
        True
      else
        (* Otherwise it is the inverse of the difference in exactly one case, zero elsewhere *)
        exists k, 0 <= k < NUM_LIMBS /\
        forall i, 0 <= i < NUM_LIMBS ->
        if i =? k then
          BinOp.mul (BinOp.sub (a.[i]) (b.[i])) diff_inv_marker.[i] = 1
        else
          diff_inv_marker.[i] = 0
    ),
  {{ eval self local from_pc ✅
    get_expected_result self local from_pc expected_cmp_result
  }}.

This is a long statement, but here is the gist of it:

• We expect the final result to be the result of the function get_expected_result applied to its parameters. This represents a structure containing various polynomial expressions, which will be useful later to combine this sub-circuit with others.
• The columns a, b, and imm can be anything. They are input variables.
• The columns opcode_beq_flag and opcode_bne_flag are also input variables, but must be consistent: only one of them can be equal to 1; the other one must be equal to 0.
• The column diff_inv_marker is an oracle variable. We assume that it has the expected property described by the predicate H_diff_inv_marker. Note that with this statement we do not assume that an oracle value exists, and assume that this is obvious. It could be verified in a second step.
• The column cmp_result is the only output variable. We compute it with get_expected_cmp_result, and it must be a boolean (0 or 1 in the field modulo $p$).

This is thanks to the setting of the output value to get_expected_cmp_result, which allows us to execute the circuit and validate all the constraints. The definition of this function is:

Definition get_expected_cmp_result {NUM_LIMBS : Z}
    (branch_equal_opcode : BranchEqualOpcode.t)
    (a b : Array.t Z NUM_LIMBS) :
    bool :=
  match branch_equal_opcode with
  | BranchEqualOpcode.BEQ =>
    if Array.Eq.dec a b then
      true
    else
      false
  | BranchEqualOpcode.BNE =>
    if Array.Eq.dec a b then
      false
    else
      true
  end.

When we have shown the determinism, we also used this function but in the other direction: to show that the constraints of the circuit imply that the output column must be equal to it.

🔍 Proof

The Rocq proof of the statement above is in Garden/OpenVM/BranchEq/core_with_monad.v. We apply the reasoning rules presented above to step through the definition of the branch_eq circuit. For the main loop, which is parameterized by an arbitrary number of NUM_LIMBS, we make a reasoning by induction to ensure that the constraints M.AssertZero are always satisfied.

Here is an extract of the proof:

eapply Complete.Let with (value := tt). {
  repeat econstructor.
  unfold local; destruct expected_cmp_result; reflexivity.
}

to verify the completeness of the line:

let* _ := M.assert_bool local.(BranchEqualCoreCols.cmp_result) in

by case reasoning over the boolean variable cmp_result.This works as we force the value of this output variable to be a boolean, as the result of the get_expected_cmp_result function lifted to a field element.

There are no automations for now to verify the completeness, but we plan on adding some as we verify more circuits.

✒️ Conclusion

We have seen here what the definition of completeness is for a circuit, how we define it in our framework Garden through reasoning rules, and how we can verify it for the branch_eq chip of OpenVM.
